EXECUTIVE
CHAIR

INSTALLATION MANUAL

Executive Chair
ASPIRELLA SERIES
Bill of Materials
S. No Image Part Name Quantity
A Caster Wheel Wheel 5x
B Five-Star Base Base 1x
C Seat Cushion Seat Cushion 1x
D Armrest Armrest 2x
E Backrest Backrest 1x
F Gas Lift Gas Lift 1x
G Screws Screws 10x
H Mechanism Mechanism 1x
I Allen Key Allen Key 1x
Safety Precautions
S. No Icon Description
1 Read Manual Icon Read and follow instructions given in the manual.
2 Two People Icon Make sure that the package is not placed on the ground.
3 No Power Tools Icon Do not use power tool.
4 No Hammer Icon Do not use hammer.
Crafted by Aspirella™
2
Step 1 of 6
Position the base on a support and insert the wheel into the base until you hear a click.
Animation of Step 1: Inserting caster wheels
Crafted by Aspirella™
3
Step 2 of 6
Install the seat mechanism on the underside of the seat cushion until it locks in place.
Animation of Step 2: Attaching mechanism
Crafted by Aspirella™
4
Step 3 of 6
Install the backrest on the unit and tighten with screws. Use an allen key.
Animation of Step 3: Attaching backrest
Crafted by Aspirella™
5
Step 4 of 6
Install the armrest on the unit and tighten with screws. Use an allen key.
Animation of Step 4: Attaching armrests
Crafted by Aspirella™
6
Step 5 of 6
Install the gas lift in the center opening of the chair base.
Animation of Step 5: Installing gas lift
Crafted by Aspirella™
7
Step 6 of 6
Install the seat assembly on the gas lift until it is fully locked.
Animation of Step 6: Final assembly
Crafted by Aspirella™
8
Inspection Check
After installation, rotate the chair to make sure the correct operation.
360 View
Crafted by Aspirella™
9
